Cincinnati Lathe

Comet

HiTech-Turn 25

Hitachi Seiki high-performance cnc turning center. It features next-generation digital servomotors on all axes for precise motion control,



Chuck Diameter                  : 250mm
Maximum Swing                 : 500mm
Distance Between Centers   : 750mm
CNC Control                       : Fanuc A/C Drive 10T

MV 3A, 3 Axis, Vertical machining center

Brand Yam
Model MV 3A

Table longitudinal travel (X-axis) 650 mm
Cross travel head (Y-axis) 450 mm
Height travel head (Z-axis) 500 mm
Table dimensions 900 x 525 mm
Max weight on the table 500 kg
Depth of throat (uprights-spindlecenter) 500 mm
Admission in spindle (ISO) ISO 40
Power on the spindle 5,5 - 7,5 kW
Control (type) CNC Fanuc OM
Number of toolholders 20
Number of rotations (from X to Y rpm) 45 - 4500 rpm



Machine Shop



Ex-Cell-O Vertical Mill



9"x 36" Table

1/2 HP Variable Speed Motor

Low: 100-640 RPM

High: 620-3800 RPM

Longitudinal Travel: 25"

Cross Travel: 13"

Verticle Travel: 16"

Quill Stroke: 6"

Spindle Taper: R8

Mighty Comet

Control: Mitsubishi M310X-Axis

Travel: 21"

Y-Axis Travel: 16"

Z-Axis Travel: 20"

Spindle Speed: 8,000 RPM

Spindle Taper: CAT 40

Spindle Motor: 10 HP

Tool Changer: 16 ATC



Cincinnati Lathe

Swing Over Bed:  17-1/8"Swing

Over Cross Slide: 9-1/2"

Distance Between Centers: 54"

Spindle Speeds: 12

Spindle Range: 25 to 1,470

RPMSpindle Motor:  7 HP

Spindle Nose: L-1

ThreadedSpindle Hole: 1-3/4"

Feeds (48): 1-1/2 to 92

T.P.I.Electrics: 230/460 Volt



Mighty Comet

Table Size: 63" x30"

X-Axis Travel: 60"

Y-Axis Travel: 30"

Z-Axis Travel: 24.5"

Spindle Speed: 6000 Rpm

Spindle Taper: 50 Taper

Tool Changer : Capacity20 ATC

Horse Power: 20 HP

Machine Weight: 25,000

Table Working Surface: 32″ x 15.7″

Maximum table load: 1,000 lbs Travel

Longitudinal Travel (X axis):  21″

Cross Travel (Y axis): 16″

Vertical Travel (Z axis):  20″Spindle

Spindle nose taper: #40

Spindle speed (gear) rpm: 6,000 Feed

Cutting feed rate (max): 393 ipm

Rapid traverse rate (X,Y,Z axis) 708 ipm ATC

Tool storage capacity-Drum: 16 pieces

Tool change time (approx)-Drum: 5 seconds Motors

Spindle drive motor (peak rating): 15 hp

Spindle drive motor (30 min rating): 10 hp

Required Air pressure:  85 psiElectric Power Consumption: 220V60 AMP



Eisele Automatic Cold Cut

 Percision Cutting
